In-Ground, Auto Turn of 180º

Lifts 400 lbs maximum at 55-60 PSI operating pressure, depending on weight of added accessories.

Compact and Portable – Lifts out and rolls away with no tools or readjustments needed.

Weighs approx. 82 lbs with seat,  57 lbs without seat.

Installs at min. 36″ straight wall.  Height in raised position — 74.5″.

Plastic piece at bottom of cylinder touches pool wall — protective wall pad for vinyl-liners available.

Mounts in deck socket — 2 3/8″ OD, 7″ depth.

No underwater installation.

All IGAT models allow maximum access from the deck for the user and any assistant.  Side to side transfers are easy – the outer armrest and footrest flip up out of the way and the mounting arm is under the seat for unobstructed wheelchair access.  Independently operable, upper and lower controls are within easy reach of the rider and anyone wanting to call the seat from the opposite location. The seats automatically turn forward into the pool/spa (clockwise is standard), travel 44″ vertically, can be stopped or reversed at any point, and can be padlocked in the deck position with the water turned off.

ADA-compliant for commercial pools.
